INPUT POWER SUPPLY: 3~380V±15%, 50/60HZ
RATED INPUT CURRENT(A): TIG: 22 | MMA: 24
RATED INPUT POWER(KW): TIG: 13 | MMA: 14
WELDING CURRENT RANGE(A): TIG: 5400 | MMA: 30350
PRE-GAS TIME RANGE(S): 0~2
HOT START CURRENT RANGE(A): 30~400
START CURRENT RANGE(A): 5~400
UP SLOPE TIME RANGE(S): 0~15
PULSE PEAK CURRENT RANGE(A): 25~400
PULSE BASE CURRENT RANGE(A): 5~380
PULSE FREQUENCY RANGE(HZ): 0.1~999
PULSE PEAK CURRENT DUTY CYCLE(%): 15~80
DOWN SLOPE TIME RANGE(S): 0~15
CRATER CURRENT RANGE(A): 5~400
POST-GAS TIME RANGE(S): 0.1~60
SPOT WELDING TIME RANGE(S): 0.01~9.99
DUTY CYCLE(40°C,10MIN): 60% 400A/26V | 100% 350A/34V
